Technical Data

• Maximum Capacity:
  90 g
• Readability Moisture Content:
  1 mg/0.01%
• Pan Size:
  3.5 in (90 mm)
• Heater Type:
  Carbon fiber
• Communication:
  USB device, RS232, USB host
• Recommended Moisture Content MC%:
  0.5% - 100%
• Adjustment:
  Temperature adjustment - mechanical (100°C, 160°C), weight adjustment - external (50 g)
• Display:
  4.3” capacitive touch screen
• Display Results:
  RG%, Temperature, Drying curve, DC%, Time, Method name, Statistics, MC%, Weight
• Heating Profiles:
  Ramp, Standard, Step, Fast
• ID Management:
  Sample name, Sample ID, Batch ID
• In-Use Cover:
  Included
• Moisture Range:
  0.01% - 100%
• Net Weight:
  9.5 lb (4.3 kg)
• Operating Range (Temp.):
  10°C - 40°C
• Operation Instructions:
  Live drying curve, On-screen instruction
• Repeatability:
  0.08% (3 g sample), 0.015% (10 g sample)
• Shut-Off Criteria:
  Timed, 5 auto, Manual, Custom - user set weight loss/time
• Status Light:
  Multi-color status light
• Stored Results:
  200
• Temperature Range:
  40°C - 200°C
• Test Library:
  20
