-40°C / -86°C. Ultra Low-Temperature - 614L / 21.7ft³. Outstanding Cooling Performance. Space Saving. TRUE DUAL™ cooling system. CFC/HCFC-free formulations.

Features

The ULUF P620 MV is a high-performance ultra-low temperature freezer designed for laboratories and research facilities requiring secure, long-term storage of sensitive biological samples, vaccines, and pharmaceuticals. Engineered with ARCTIKO's TRUE DUAL™ cooling technology, this freezer ensures continuous operation, maintaining temperatures as low as -86°C – even in the event of a compressor failure.



  • Superior temperature stability: Reaches -80°C in under 4 hours and ensures rapid recovery after door openings.
  • TRUE DUAL™ technology: A dual-compressor system provides backup cooling, keeping samples safe at -70°C in case of failure.
  • Eco-friendly and energy-efficient: Utilises natural refrigerants with low global warming potential (GWP < 4), reducing environmental impact.
  • Advanced security and control: A 7" touchscreen V700 controller with multiple alarms, RFID smart lock, and password protection for added security.
  • Multi-voltage compatibility: Operates across 100–240V for seamless global integration without the need for adapters.
  • Durable and ergonomic design: Features adjustable perforated shelves (holding up to 50 kg), a one-grip handle, and four insulated inner doors to minimise temperature loss.
  • Comprehensive data logging: Includes a USB port for data downloads, optional RS485 connectivity, and temperature chart recording capabilities.



Combining cutting-edge technology with user-friendly features and environmental responsibility, the ULUF P620 MV is the ideal choice for laboratories needing reliable ultra-low temperature storage.

Specifications

Overview

  • Nominal Height:
    78.7" (199.9 cm)
  • Nominal Width:
    40.75" (103.51 cm)
  • Nominal Length:
    33.84" (85.95 cm)
  • Internal Height:
    51.97" (132.0 cm)
  • Internal Width:
    29.37" (74.6 cm)
  • Internal Length:
    24.41" (62.0 cm)
  • Capacity:
    21.7

Main Specifications

  • Temperature Range:
    -40°C to -86°C
  • Max. Ambient Temperature:
    32°C
  • Capacity (L):
    614
  • Weight (kg):
    247
  • Insulation (mm):
    120
  • Cooling Technology:
    Dual system / Static
  • Controller Model / Probe Type:
    V700 / Pt100
  • Power Supply Voltage (V):
    100 - 240
  • Frequency (Hz):
    50 / 60
  • Power Consumption (kWh/24h):
    8.4

Refrigerant & Cabinet

  • Number of Compressors:
    2
  • Refrigerant:
    GG20
  • Interior Cabinet Material:
    Stainless steel
  • Exterior Cabinet Material:
    Painted steel
  • Colour (Exterior Cabinet):
    White
  • Foam Type:
    Polyurethane
  • VIP Vacuum Insulated Panels:
    Yes

Shipping

  • Shipping Weight (kg):
    387
  • Shipping Dimensions WxDxH (cm):
    115 x 127 x 225
  • Shipping Volume (m³):
    3.29
