Ohaus - 30392031 - Hotplate, Mini, Fixed, HSMNHP4CFT, US
Features
Rugged OHAUS Mini Hotplates and Stirrers can heat and stir up to 1000 ml of water on the 4 x 4 in. (102 x 102 mm) ceramic top plate surface. These units are ideal for educational and other lab environments that require simple, every-day heating and stirring. All models feature a built-in support rod holder with a locking knob, which accepts the optional support rod kit. Stirring models include 1.5 in. (38 mm) PTFE coated stir bar.
- Applications: Boiling Water, Dissolving Buffers and Reagents, Preparing Media, Concentrating Samples
- Display: N/A
- Operation: Detachable 3-wire cord and plug (included)
- Communication: N/A
- Construction: Valox housing, basic control knobs, 1.5 inch (3.8 cm) stir bar (included with Stirring models), On/Off toggle switch (Fixed Temperature models)
- Design Features: N/A
Specifications
Overview
-
Nominal Height:5" (12.7 cm)
-
Nominal Width:6" (15.24 cm)
-
Nominal Length:7.9" (20.07 cm)
Technical Data
-
Function:Heating
-
Capacity:1000 mL
-
Plate Construction:Ceramic
-
Plate Size:4 in x 4 in (10.2 cm x 10.2 cm)
-
Temp. Range:500°C
-
Control:Analog
-
Net Weight:4 lb (1.8 kg)
-
Power:120V, 1.8A, 50/60Hz
-
Power Consumption:200 W
-
Safety Certification:TUV
-
Working Environment:41°F - 104°F, 80% RH, Non-condensing (5°C - 40°C, 80% RH, Non-condensing)
