American Biotech Supply - ABT-HC-UCFS-0520 - 4 Cu. Ft. Capacity Premier Undercounter Freezer Freestanding (-20°C)

Features
The Premier Freestanding Undercounter Freezers feature a microprocessor temperature controller and display, allow for precise temperature control, verification and recovery versus mechanical style thermostats. Critical samples and supplies are security backed with an extensive package of audible and visual alarms.
Periodic defrosting is required.
The Freestanding models ("UCFS") require 4" of clearance around back and sides of the unit for proper ventilation. Improper installation will void the warranty and will lead to temperature maintenance issues, overheating and possible failure.
Environmentally friendly, natural hydrocarbon (HC) refrigerants (not containing hydrofluorocarbons) vastly reduce global-warming potential (GWP) while meeting new EPA/SNAP mandates and UL, ASHRAE compliance guidelines.
Details
- 4 Cu. Ft. Capacity
- One solid swing door, right hinged, not reversible
- Microprocessor temperature controller
- 2 fixed shelves
- Bottom footed shelf to allow air circulation
- Back wall evaporator cover
- Keyed door lock
- Magnetic door gasket for positive seal
- Recessed door handle
- Leveling legs
- LED interior light
- Probe access port (0.4")
- White cabinet and door
- High density urethane foam cabinet and door insulation
- HFC-free refrigerant (R600a), foam insulation and packaging
- Two year parts and labor warranty, plus an additional three year compressor parts only warranty
Temp Controller
- Microprocessor temperature controller
- Digital temperature display
- Audible and visual high and low temperature alarms
- 2 probes, 1 in air and 1 in sample bottle
- Remote alarm contacts
- Adjustable operating temperature range: -15°C - -25°C
Specifications
Overview
-
Nominal Height:32.19" (81.76 cm)
-
Nominal Width:23.63" (60.02 cm)
-
Nominal Length:24.25" (61.6 cm)
-
Internal Height:26" (66.04 cm)
-
Internal Width:19" (48.26 cm)
-
Internal Length:16" (40.64 cm)
-
Capacity:4
Specifications
-
Defrost:Manual
-
Door:1 Solid
-
Int Door:0
-
Shelves:2 Fixed
-
Refrigerant:R600a
-
H.P.:0.125
-
Amps:1.4
-
Weight:91 lbs.
Drawings
-
ABT-HC-UCFS-0520 Ext CutsheetVisit Link
-
ABT-HC-UCFS-0520 Int CutsheetVisit Link
Useful Links
-
ABT-HC-UCFS-0520 SpecSheetVisit Link
