Technical Data

• Optical System:
  Colour Corrected Infinity Optical System (CCIS)
• Inclination:
  30° inclined, 360° rotating
• Interpupillary Distance:
  50-75 mm
• Diopter Adjustment:
  On both eyepieces, ±5 diopter
• Eyepieces:
  Widefield N-WF10X/22mm with Diopter Adjustment
• Objective Classification:
  CCIS EC-H Plan Achromatic, DIN
• Objectives:
  4X/0.10 (WD 15.9mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.5mm), 100X/1.25/S-Oil (WD 0.15mm)
• Objective Mounting Thread:
  W 4/5" x 1/36" (RMS standard)
• Stand Type:
  Upright
• Stage:
  Mechanical stage with built-in low position rackless coaxial stage control, ceramic insert and sample holder
• Stage Size:
  180 x 170 mm
• Stage Size X&Y:
  80 x 55 mm
• Condenser:
  Focusable and centerable Swing-out Abbe condenser N.A. 0.90/0.13
• Diaphragm:
  Iris diaphragm
• Focus Mechanism:
  Coaxial coarse and fine focusing system with tension adjustment
• Fine Focus Precision:
  1 µm
• Focusing Stroke:
  27 mm
• Upper Limit Stop:
  Upper limit stop preset but adjustable
• Filter Holder:
  On top of the illuminator with fixing cap
• Illumination Features:
  Auto-OFF and Light Memory function. External lamphouse
• Transformer:
  Internal
• Power Supply:
  100-240V (CE)
• Accessories Included:
  Dust cover, power cord, Allen key, immersion oil (5ml), blue filter, spare fuse, arm rest
• Net Weight:
  14.2kg
