Top-of-the-Line Compact Scales for Even the Most Complex Industrial Applications.

Product Range

SKU Name
30212873 Ohaus - 30212873 - Ranger™ 7000 Bench Compact Scale, R71MD60 AM
30088843 Ohaus - 30088843 - Ranger™ 7000 Bench Compact Scale, R71MHD35 AM
30070312 Ohaus - 30070312 - Ranger™ 7000 Bench Compact Scale, R71MD35 AM
30088840 Ohaus - 30088840 - Ranger™ 7000 Bench Compact Scale, R71MHD3 AM
30088841 Ohaus - 30088841 - Ranger™ 7000 Bench Compact Scale, R71MHD6 AM
30088842 Ohaus - 30088842 - Ranger™ 7000 Bench Compact Scale, R71MHD15 AM
30070311 Ohaus - 30070311 - Ranger™ 7000 Bench Compact Scale, R71MD15 AM
30070310 Ohaus - 30070310 - Ranger™ 7000 Bench Compact Scale, R71MD3 AM
30070289 Ohaus - 30070289 - Ranger™ 7000 Bench Compact Scale, R71MD3 AM

Features

For Ranger 7000, there is one resounding theme: it offers the best of every ingenious feature that make OHAUS industrial products the right tools for your toughest weighing jobs. Ranger 7000 boasts the highest resolution, largest display, most application modes and connectivity options, as well as the largest memory library of any industrial bench scale in the OHAUS portfolio.


Applications


Weighing, Parts Counting with Auto Optimization, Percent Weighing, Advanced Checkweighing, Animal/Dynamic Weighing, Display Hold, Filling, Formulation, Differential Weighing, Density Determination, Sieve Analysis


Display


4.3" (109 mm) Full-color WQVGA graphic display with user-controlled brightness


Operation


AC power (included) or rechargeable battery (accessory sold separately)


Communication


Easy access communication port including standard USB and RS232 (included) and an optional third port of RS232 or Ethernet (accessories sold separately). GLP/GMP Data Output with Real Time Clock. Data Transfer Function.


Construction


Modular design, die-cast housing, removable stainless steel platform, integral weigh below hook, menu lock switch, level indicator


Design Features


Checkweighing lights with selectable operation and audible signal settings, several selectable operating languages, selectable environmental and autoprint settings, stability indicator, overload/underload indicators, selectable brightness settings, auto-dim, auto-sleep, auto tare, chain tare.


Watch the video

Specifications

Overview

Technical Data

  • Second Scale Input:
    Yes
  • Communication:
    2nd RS232 (Available as an Accessory), Ethernet (Available as an Accessory), USB (Included), RS232 (Included)
  • Dimensions:
    16.5 in x 4.5 in x 11 in (420 mm x 114 mm x 280 mm) (LxHxW)
  • Display:
    4.3"/10.9cm TFT Graphic LCD
  • In-Use Cover:
    Included
  • Legal for Trade:
    NTEP Certified, Measurement Canada Approved
  • Outputs:
    2 In/4 Out digital I/O
  • Platform Construction:
    Stainless Steel
  • Power:
    Rechargeable Battery (Not Included), AC Power (Included)
  • Protection Rating:
    IP54
  • Tare Range:
    To capacity by subtraction
  • Transportation Case:
    Not Applicable
  • Units of Measurement:
    Gram, Kilogram, Pound, Ounce, Custom, Pound, Ounce
