Ohaus - Multi-Position Stirrer
Features
Powerful Magnetic Stirrers available in either four or nine position capacities provide precise speed control that deliver repeatable performance. Offered in both digital and non-digital models.
Applications
Dissolution Studies, Titrations, Media/Reagent Preparations, Synchronized Stirring of multiple samples.
Display
Independent LED displays for speed and time (on digital models), Knob with 1-10 dial markings (on non-digital models).
Construction
Cast aluminum housing, glass filled nylon top plate. Includes stir bars to accommodate each stirring position.
Design Features
Speed ramping feature slowly increases motor speed for enhanced coupling & improved stirring. Microprocessor-controlled for precise speed regulation. Timer counts up or when programmed to a set time will turn off stirring & sound alarm when timer reaches zero.
Specifications
Overview
-
Nominal Height:4" (10.16 cm)
-
Nominal Width:11" (27.94 cm)
-
Nominal Length:17" (43.18 cm)
Technical Data
-
Timer:1 second - 160 hours
-
Control:Analog
-
Power Consumption:75 W
-
Net Weight:14 lb (6.3 kg)
-
Plate Construction:Glass Filled Nylon
-
Plate Size:12.5 in x 11 in (318 mm x 279 mm)
-
Safety Certification:UL, cUL
-
Working Environment:41°F - 104°F, 80% RH, Non-condensing (5°C - 40°C, 80% RH, Non-condensing)
-
Speed Range:60 rpm to 1400 rpm
-
Power:120V, 1.3A, 50/60Hz
