Affordable Balance to Achieve Reliable Results.

Features

The Pioneer PX Series combines essential weighing functionality with competitive performance, offering high accuracy and repeatability for applications in laboratory, industrial and educational settings. The PX is affordably priced, and intuitively designed for intelligent operation with a second line display for additional information, and USB and RS232 connectivity for easy communication.



The PX offers high accuracy and repeatability for essential weighing applications in laboratory, industrial and educational settings at an economical pricepoint. Featuring a cast metal lower housing, sub-pan and stainless steel weighing pan, the PX is durably constructed for versatile, long-term use. Pioneer features a second line display for additional information or guidance, a static removal bar for convenient grounding, and USB connectivity.



Applications



Basic Weighing, Parts Counting, Percent Weighing, Animal Weighing, Density Determination, Formulation.



Display



2-Line LCD with Backlight



Operation



Power Adaptor



Communication



RS232, USB



Construction



Metal base, plastic top housing, removable stainless steel pan, weigh-below-hook



Design Features



User-selectable environmental filters and brightness settings, auto-tare, auto-dim, user-selectable span calibration points, software lockout and reset menu, userselectable communication settings and data print options, user-definable project and user IDs, software overload/underload indicator, stability indicator, four operating languages.

Specifications

Overview

  • Nominal Height:
    3.98" (10.11 cm)
  • Nominal Width:
    8.23" (20.9 cm)
  • Nominal Length:
    12.64" (32.11 cm)

Technical Data

  • Maximum Capacity:
    12,000 g
  • Readability:
    0.1 g
  • Pan Size:
    248 mm x 193 mm
  • Auxiliary Display Model:
    Available as an Accessory
  • Communication:
    USB, RS232
  • Display:
    2-Line LCD with Backlight
  • In-Use Cover:
    Included
  • Linearity:
    ± 0.2 g
  • Minimum Weight (USP, 0.1%, Typical):
    160 g
  • Net Weight:
    7.7 lb (3.5 kg)
  • Pan Construction:
    Stainless Steel
  • Power:
    AC Adapter (Included)
  • Repeatability, Typical:
    0.1 g
  • Stabilization Time:
    1 s
  • Tare Range:
    To capacity by subtraction
  • Units of Measurement:
    Singapore Tael, Pennyweight, Ounce Troy, Kilogram, Grain, Tical, Custom, Milligram, Newton, Momme, Taiwan Tael, Baht, Gram, Hong Kong Tael, Pound, Tola, Mesghal, Ounce, Carat
  • Working Environment:
    operability guaranteed between 41°F and 104°F, 50°F - 86°F, 80%RH, non-condensing (operability guaranteed between 5°C and 40°C, 10°C - 30°C, 80%RH, non-condensing)
