Ohaus - 30648433 - i-DT33XW Stainless Steel Washdown Indicator i-DT33P AM EZ
Features
Designed with affordability in mind for basic industrial applications, the i-DT33P indicator combines high-impact ABS housing with a large multicolor backlit LCD display and bi-directional RS232. The i-DT33P also features software for weighing, parts counting, checkweighing, and totalization.
Applications
Weighing, parts counting, checkweighing, and totalization
Display
7-segment LCD with multicolor backlight
Operation
Internal power supply with power cord (included), 6C (LR14) batteries (not included) or rechargeable battery
Communication
Standard RS232 and optional USB device or Ethernet
Construction
ABS housing and powder-coated steel mounting bracket
Specifications
Overview
-
Nominal Height:7" (17.78 cm)
-
Nominal Width:3.2" (8.13 cm)
-
Nominal Length:9.9" (25.15 cm)
Technical Data
-
Resolution:30,000
-
Resolution (Certified):6,000
-
Battery Life:100 hours with rechargeable battery, 360 hours with disposable batteries
-
Outputs:Not applicable
-
Second Scale Input:Not applicable
-
Protection Rating:Not applicable
-
Units of Measurement:Metric tons, Gram, Kilogram, Pound, Ounce, Pound, Ounce
-
Legal for Trade:NTEP Certified, Measurement Canada Approved
-
Display:7-segment LCD with multicolor backlight
-
Working Environment:-10°C - 40°C, 85%RH, non-condensing (14°F - 104°F, 85%RH, non-condensing)
-
Tare Range:To capacity by subtraction
-
Net Weight:2.9 lb (1.3 kg)
-
Power:6 C (LR14) batteries (not included), rechargeable battery (not included), AC power (included)
-
Communication:Ethernet (available as an accessory), RS232 (included), USB (available as an accessory)
