Designed for Routine Weighing Applications in Your Workplace.

Features

Offering accuracy and repeatability in essential weighing applications in laboratory, industrial and education settings, PR Analytical and Precision Balances deliver competitive performance at an economical price. Featuring RS232 connectivity for easy communication, and a backlit display and a simple interface for uncomplicated operation, the PR is perfectly designed for your workplace.


Applications


Basic Weighing, Parts Counting, Percent Weighing


Display


Backlit Liquid Crystal Display (LCD)


Operation


AC adapter (included)


Communication


RS232 (one port included)


Construction


ABS top housing, removable stainless steel pan, removable glass draftshield with sliding top door, integrated weigh-below-hook, security bracket, calibration lock


Design Features


User-selectable environmental filters and brightness settings, auto-tare, auto-dim, user-selectable span calibration points, software lockout and reset menu, user-selectable communication settings and data print options, user-definable project and user IDs, software overload/underload indicator, stability indicator

Specifications

Overview

  • Nominal Height:
    11.9" (30.23 cm)
  • Nominal Width:
    7.9" (20.07 cm)
  • Nominal Length:
    12.5" (31.75 cm)

Technical Data

  • Maximum Capacity:
    220 g
  • Readability:
    0.001 g
  • Pan Size:
    4.7 in (120 mm)
  • Internal Calibration:
    Not Applicable
  • Draftshield:
    Included
  • Auto Door:
    Not Applicable
  • Auxiliary Display Model:
    Available as an Accessory
  • Battery Life:
    Not Applicable
  • Communication:
    RS232
  • Display:
    LCD with backlight
  • In-Use Cover:
    No
  • Legal for Trade:
    No
  • Linearity ±:
    0.002 g
  • Minimum Weight (USP, 0.1%, Typical):
    2 g
  • Net Weight:
    10 lb (4.5 kg)
  • Pan Construction:
    Stainless Steel
  • Power:
    AC Adapter (Included)
  • Repeatability, Typical:
    0.001 g
  • Stabilization Time:
    2 s
  • Tare Range:
    To capacity by subtraction
  • Units of Measurement:
    Milligram, Pennyweight, Ounce Troy, Newton, Taiwan Tael, Gram, Kilogram, Grain, Pound, Ounce, Carat, Custom
  • Working Environment:
    50°F - 104°F, 80%RH, non-condensing, 50°F - 86°F, 80%RH, non-condensing (10°C - 40°C, 80%RH, non-condensing, 10°C - 30°C, 80%RH, non-condensing)
