Ohaus - 30424078 - Indicator, TD52P AM

Ohaus - 30424078 - Indicator, TD52P AM

Ohaus - 30424078 - Indicator, TD52P AM

Contact Brent for Assistance

Need help right away? Give our customer service team a call for immediate attention

(510) 909-5846
Brent Kolhede

Ask About This Item

Add the product to a quote to receive more information.

Ask an Expert
Multifunctional Indicator for Standard Industrial Applications.

Features

The OHAUS next generation Defender 5000 Series multifunctional indicator is ideal for use in conjunction with bench and floor scales for a multitude of applications including production, packaging, inventory and shipping. Built durably and equipped with advanced features such as maximum configurability print output, GMP/GLP data output, library/user management and multiple connectivity options - the Defender 5000 Series is designed to handle demanding industrial and commercial applications.


Applications


Weighing, Parts Counting, Percent Weighing, Check Weighing, Dynamic Weighing (Display Hold), Filling.


Display


Backlit Liquid Crystal Display (LCD), 256 x 80 pixels.


Operation


Internal power supply with power cord (included) or rechargeable battery (sold separately as an accessory).


Communication


Easy access communication ports including RS232 and Micro SD slot (included), second RS232/RS485/USB device, Ethernet and WiFi/Bluetooth, Discrete I/O and Analog Output (sold separately as accessories),GLP/GMP data output with real-time clock.


Construction


ABS plastic housing.


Design Features


Check weighing symbols with selectable operation and audible signal settings, menu lock switch, multiple operating languages, selectable environmental and auto-print settings, stability indicator, overload/underload indicators, selectable adjust contrast settings, auto-dim, auto-off, auto tare, screensaver.

Specifications

Overview

  • Nominal Height:
    7.6" (19.3 cm)
  • Nominal Width:
    3" (7.62 cm)
  • Nominal Length:
    10.4" (26.42 cm)

Technical Data

  • Resolution:
    75,000
  • Resolution (Certified):
    10,000
  • Battery Life:
    20 Hours with Rechargeable Battery
  • Outputs:
    4 - 20mA, 2 In/4 Out digital I/O
  • Communication:
    Ethernet (Available as an Accessory), 2nd RS232/RS485/USB (available as an accessory), RS232 (Included), USB (Available as an Accessory), WiFi/Bluetooth (available as an accessory)
  • Display:
    Dot matrix LCD with white LED backlight
  • Legal for Trade:
    NTEP Certified, Measurement Canada Approved
  • Net Weight:
    3 lb (1.5 kg)
  • Power:
    Rechargeable Battery (Not Included), AC Power (Included)
  • Tare Range:
    To capacity by subtraction
  • Units of Measurement:
    Metric Tons, Gram, Kilogram, Pound, Tonne, Custom, Ounce
  • Working Environment:
    14°F - 104°F, 85%RH, non-condensing (-10°C - 40°C, 85%RH, non-condensing)
