Technical Data

• Sensor Type:
  sCMOS
• Sensor Size:
  1/3"
• Imaging Area:
  5.44 x 3.07 mm
• Capture Resolution:
  4MP (2560 x 1440 pixels)
• Live Display Mode Through Wi-Fi:
  1280 x 720, 1920 x 1080 pixels (Full HD)
• Live Display Mode Through Ethernet:
  1280 x 720, 1920 x 1080 pixels (Full HD)
• Pixel Size:
  2.0 x 2.0 μm
• Scan Mode:
  Progressive
• Shutter Mode:
  Rolling shutter
• Data Transfer:
  Wi-Fi (2.4 & 5 GHz), Ethernet
• Max. Frames Per Second (FPS):
  1920 x 1080 @ 30 FPS, 1280 x 720 @ 30 FPS (depending on Wi-Fi strength)
• Exposure Time:
  0.03 msec to 0.03 sec
• Operating Temperature:
  From -10 to +50 degrees Celsius, non-condensing
• Max. Signal to Noise Ratio:
  38.3 dB
• Dynamic Range:
  64.6 dB
• Sensitivity:
  1.9V/Lux-sec (550nm)
• Support Device:
  universal web browser (HTML5)
• Supported OS:
  Windows 7/8/10, macOS, Android 4.0 or higher, iOS 7 or higher
• Minimum Computer Requirements:
  2GHz dual-core, RAM memory 2GB, video memory min. 512MB
• Lens Mount:
  C-mount
• Focusable Lens:
  12 mm
• Software:
  Motic Images Plus 3.1 for Windows, macOS and Linux, MotiConnect app for iOS and Android
• Functions:
  Still image and video capture, live and still image measurement, image adjustments, white balance, automatic & manual exposure, individual objective calibration system
• Power Supply:
  12V (external power supply)
• Package Includes:
  CS ring adaptor, focusable lens, 30mm and 38mm eyepiece adapters, Motic 4-dot calibration slide, macro calibration card, macro-tube, Motic Images Plus 3.1 for Windows/macOS/Linux, universal power
• Other Features:
  USB 2.0 port for external devices
