Motic’s new sCMOS cameras, designed by German engineers and manufactured by professionals represent an impressive impetus to microscope camera performance.

Features

Motic’s new sCMOS cameras, designed by German engineers and manufactured by professionals represent an impressive impetus to microscope camera performance. With a member of this product line the door for new application fields opens wide. The accelerated data readout enables to work on fast phenomena in biology and industry.


Maximum Details.


If it is about maximum resolution for printing purposes, Moticam S12 is your choice. A 25 fps frame rate manages the largest data volume of Motic's S-LINE. If resolution in display or for printing purposes is in your focus, Moticam S12 is an offer you should not refuse.


The right choice for challenging tasks in professional fields. The Moticam S Series offers smooth navigation, high colour fidelity, and crisp images designed by German engineers. Time efficiency in its best resolution from HD up to QHD+.


The Speedy Standards


Moticam S1 and Moticam S3 are designed for the fast and accurate imaging of results in biomedical environments or industry. Ultra-fast image capture and smooth navigation through your samples in live mode. Excellent balance of speed and image quality.


The Hi-Res Experts


Moticam S6, Moticam S12 and Moticam S20 are focused on resolution, ready to reveal the tiniest detail of your sample on a large screen. Documentation in printed format is no problem at all. The data volume created by the 6/12/20MP sensors should be handled by a computer with USB 3.1 Gen.1 port for faster transmission.


The Hi-Sensitives


Moticam Pro S5 Lite and Moticam Pro S5 Plus are characterized by a large 2/3" sCMOS sensor and a Global Shutter for speedy handling of moving phenomena. This camera line takes Sensitivity as a priority: Fluorescence, Polarization, and Darkfield are the applications the engineers had in mind.


Watch the video

Watch the video

Watch the video

Watch the video

Watch the video

Watch the video

Specifications

Overview

Technical Data

  • Sensor Type:
    sCMOS
  • Sensor Size:
    1/1.7"
  • Imaging Area:
    9.33 mm (Diagonal)
  • Capture Resolution:
    12MP
  • Live Display Mode Through USB:
    4000 x 3000, 2048 x 1080 pixels
  • Pixel Size:
    1.85 x 1.85 μm
  • Scan Mode:
    Progressive
  • Shutter Mode:
    Rolling Shutter
  • Data Transfer:
    USB 3.1
  • Max. Frames Per Second (fps):
    4000 x 3000 @ 25fps, 2048 x 1080 @ 50fps
  • Exposure Time:
    22 μsec to 2 sec
  • Operating Temperature:
    From -10 to +60 Degrees Celsius (non-condensing)
  • Max. Signal To Noise Ratio:
    0.1mV @ 1/30 sec
  • Sensitivity:
    280mV(G) @ 1/30 sec
  • Support Device:
    TWAIN, SDK and DirectShow Driver
  • Supported OS:
    Windows 7/8/10, MAC OSX, Linux or higher
  • Minimum Computer Requirements:
    2GHz dual-core, RAM memory 2GB, Video memory min. 512 MB
  • Lens Mount:
    C-Mount
  • Software:
    Motic Images Plus 3.0 for Windows 10, MAC OSX10.9, Linux UBUNTU1604 or higher
  • Functions:
    Still image and video capture, live and still image measurement, image adjustments, white balance, automatic & manual exposure, individual objective calibration system
  • Power Supply:
    5V (From USB Port)
  • Package Includes:
    CS ring adaptor, USB 3.1 cable, Motic 4-dot calibration slide, Motic Images Plus 3.0 for PC/OSX/Linux
