Lab Research Products - LRP-HC-MFP-P - Plus Series Manual Defrost Laboratory Freezer

Product Range
| SKU | Name |
|---|---|
| LRP-HC-MFP-20P | Lab Research Products - LRP-HC-MFP-20P - 20 Cu. Ft. Plus Series Manual Defrost Laboratory Freezer |
| LRP-HC-MFP-17P | Lab Research Products - LRP-HC-MFP-17P - 17 Cu. Ft. Plus Series Manual Defrost Laboratory Freezer |
| LRP-HC-MFP-14P | Lab Research Products - LRP-HC-MFP-14P - 14 Cu. Ft. Plus Series Manual Defrost Laboratory Freezer |
Features
These manual defrost laboratory freezers offer professional cold storage for scientific and industrial settings. Units come equipped with temperature alarms, keyed door locks, probe access, and precise temperature monitoring through microprocessor control.
Our Plus Series freezers include premium additions such as extensive alarm systems and digital touch pad displays. All units run on natural, hydrocarbon refrigerant for environmental health and energy efficiency.
General Warranty: Two (2) year parts and labor warranty
Compressor Parts Warranty: Five (5) year compressor parts warranty
Warranty Disclaimer: Product requires 4" of clearance around back and sides of the unit for proper ventilation. Improper installation will void the warranty and will lead to temperature maintenance issues, overheating, and possible failure.
Controller, Configuration, Alarms and Monitoring
- Controller technology: Microprocessor temperature controller with digital temperature display, °C/°F switchable
- Display technology: Bi-Colored LED display and alarm module with 1°C resolution, touchpad controls, resettable 1-point min/max history
- Adjustable Temperature Range: -15°C to +25°C
- External alarm connection: State switching remote alarm contacts
- Alarms: Audible and visual high and low temperature alarms, sensor error alarm, power failure alarm, alarm validation (audible, visual, and remote alarm), and alarm mute with ring back
- Controller probe: 2 Probes, 1 in air and 1 in sample bottle.
- Disclaimers: Defrosting of the unit will need to be performed periodically to prevent severe ice build-up. Indoor use only, +18°C to +26°C (+65°F to +78°F), 70% RH Specifications are subject to change.
Specifications
Overview
Technical Data
-
Door:Solid, right hinged, magnetic door gasket for positive seal
-
Freezer Compartments:2 Inner Doors
-
Baskets:Non-applicable
-
Mounting:Leveling Legs
-
Interior Lighting:Non-applicable
-
Airflow management:Non-applicable
-
External probe access:Rear wall port (3/4") dia
-
Insulation:Cabinet is foamed-in-place with EPA compliant high density urethane foam
-
Exterior materials:White powder coated steel
-
Access Control:Keyed door lock
-
Facility Electrical Requirement:115V, 60 Hz
-
Agency Listing and Certification:ETL Listed, Energy Star Certified
Refrigeration System
-
Refrigerant:R290
-
Defrost:Manual
