This 30 cu. ft. hazardous location refrigerator is meticulously engineered for the safe and reliable storage of volatile materials in potentially hazardous work environments.

Features

It's the ideal choice for industrial environments requiring strict safety protocols. This unit utilizes EPA SNAP compliant natural refrigerants for environmentally responsible operation. Maintaining a consistent temperature range of 2°C to 10°C with tight temperature uniformity, this refrigerator provides dependable cold storage backed by microprocessor technology. It features a durable white powder-coated steel exterior, with a keyed door lock for added security. Adjustable interior shelving allows for versatile organization. With low energy consumption and precise temperature control, the LRP-HC-ERS-30 is a safe and efficient solution for hazardous laboratory locations and industrial settings.

Specifications

Overview

  • Nominal Height:
    72.5" (184.15 cm)
  • Nominal Width:
    35.75" (90.81 cm)
  • Nominal Length:
    35.5" (90.17 cm)
  • Internal Height:
    65" (165.1 cm)
  • Internal Width:
    32" (81.28 cm)
  • Internal Length:
    22.5" (57.15 cm)
  • Capacity:
    30

General Description and Application

  • Door:
    One solid swing, right hinged, stainless steel door handle, magnetic door gasket
  • Shelves:
    Five adjustable
  • Drawers:
    Non-applicable
  • Mounting and Installation:
    Leveling legs
  • Interior Lighting:
    Non-applicable
  • Airflow Management:
    Forced draft circulation
  • External Probe Access:
    3/4" probe access port on rear wall
  • Insulation:
    EPA compliant high density urethane foam
  • Exterior Materials:
    Powder coated steel
  • Access Control:
    Keyed door lock
  • General Warranty:
    Two (2) year parts and labor warranty
  • Compressor Warranty:
    Five (5) year compressor parts warranty
  • Product Weight (lbs):
    320
  • Shipping Weight (lbs):
    350
  • Rated Amperage:
    3.1 Amps
  • Power Plug/Power Cord:
    Power cord not included - final power connections at site must be hardwired to meet local codes
  • Facility Electrical Requirement:
    110 - 120V AC, 15A breaker
  • Agency Listing and Certification:
    UL and c UL listed, meets NFPA and OSHA guidelines for hazardous locations, Class 1, Division II, Groups C & D

Performance

  • Uniformity (Cabinet Air):
    +/- 1.6°C
  • Stability (Cabinet Air):
    +/- 1.5°C
  • Maximum Temperature Variation (Cabinet Air):
    4.6°C Total
  • Pull Down Time to Nominal Operating Temp:
    <35 min (empty)
  • Energy Consumption (kWh/day):
    <1.5 kWh/day
  • Average Heat Rejection (BTU/hr):
    500 BTU/hr

Refrigeration System

  • Compressor:
    Hermetic, variable speed
  • Refrigerant:
    EPA SNAP compliant R600a isobutane
  • Condenser:
    Static - exterior walls of cabinet
  • Evaporator:
    Fin and tube design, high efficiency fan, hazardous location rated
  • Defrost:
    Off-Cycle defrost, no heat added
