Horizontal laminar flow cabinet, Gen 3, stainless steel sides (6ft/1.8m W, 3ft/0.9m H), 115 VAC, 50/60 Hz.

Features

Scientific researches require complicated laboratory procedures and an expensive set of equipment. These laboratory equipment normally run for an average of 8 hours a day, which leads to substantial consumption of your power and expensive electricity bill. But worry no more, we have a solution for you! Airstream® Gen 3 Horizontal Laminar Flow Cabinets use energy-efficient technology. As a manufacturer of premium laminar flow cabinets, Esco does not settle until the best is achieved. To deliver the finest experience possible, every feature of a cabinet is carefully considered and fulfilled.



Esco's laminar air flow cabinet is a product of robust engineering combined with strategic ergonomic design. It provides long-term reliability and ultimate user comfort making it ideal for non-hazardous applications that need a sterile environment.



Applications



  • Plant Tissue Culture
  • Media Plate Preparation
  • Electronics Inspection
  • Medical Device Assembly



High-Quality Construction



  • Stainless steel worktop
  • Spill-retaining design will ensure containment of accidental liquid spills



Quiet Operation



  • Comfortable low noise at 52 dBA
  • Reduce fatigue and improve work concentration



ULPA Filter



  • 10x Filtration efficiency of HEPA filter Creates ISO Class 3 work zone instead of industry-standard ISO Class 5



Energy Efficient



  • Powered by latest generation DC ECM motor, that is more efficient than legacy ECM and VFD motors
  • 70% Energy savings compared to AC motor
  • Stable airflow, despite building voltage fluctuations & filter loading



Isocide™ Antimicrobial Powder Coating



  • Eliminates 99.9% of surface bacteria within 24 hours of exposure

Specifications

Overview

  • Nominal Height:
    56" (142.24 cm)
  • Nominal Width:
    76.8" (195.07 cm)
  • Nominal Length:
    30.8" (78.23 cm)
  • Internal Height:
    34.5" (87.63 cm)
  • Internal Width:
    71.4" (181.36 cm)
  • Internal Length:
    24.4" (61.98 cm)

General Specifications

  • Nominal Size:
    6 ft (1.8 m)
  • Sound Emmision Per IEST-RPCC002.2:
    59.4 dBA
  • LED Lamp Intensity at Zero Ambient:
    1001 Lux(93 fc)
  • Cabinet Full Load Amps (FLA):
    11.5 A and 6.5 A
  • Cabinet Nominal Power (W):
    365
  • Heat Rejected, BTU Per Hour:
    1245
  • Shipping Weight:
    301 Kg (664 lbs)
  • Shipping Dimensions, Maximum (W x D x H):
    2200 x 900 x 1590 mm (86.6" x 35.4" x 62.5")
  • Shipping Volume, Maximum:
    3.3 m³ (116.5 ft³)
  • Average Airflow Velocity:
    0.45 m/s (90 fpm) at initial Set Point
  • ULPA Filter Typical Efficiency:
    > 99.999% at particle size between 0.1 to 0.3 μm
  • Electrical - Power Rating 9:
    110-130 VAC, 50/60 Hz, 1 phase

Cabinet Construction

  • Main Body:
    1.2 mm (0.05") 18 gauge electro-galvanized steel with white oven-baked epoxy-polyester powder-coated finish
  • Work Zone:
    1.2 mm (0.05") 18-gauge stainless steel, grade 304, with 4B finish
  • Side Walls:
    1.2 mm (0.05") 18 gauge stainless steel, grade 304, with 4B finish
