Horizontal laminar flow cabinet, Gen 3, simple switches, stainless steel sides (5ft/1.5m W, 2.5ft/0.8m H) 115 VAC, 50/60 Hz.

Features

Esco Airstream® Horizontal Flow Cabinet blends in the latest laminar flow technology and innovation to provide protection for your samples and processes. This equipment is powered by the latest generation DC ECM motor and offers an ISO Class 3 work zone. It also features an easy-to-use simple switch for light and blower operation and a manually adjustable UV timer.



High-Quality Construction



  • Stainless steel worktop
  • Spill-retaining design will ensure containment of accidental liquid spills



Quiet Operation



  • Comfortable low noise at 52 dBA
  • Reduce fatigue and improve work concentration



ULPA Filter



  • 10x Filtration efficiency of HEPA filter Creates ISO Class 3 work zone instead of industry-standard ISO Class 5



Rocker Switches



  • Easy-to-use switches for cabinet's operation
  • Displays filter loading status
  • Manually adjustable UV timer



Isocide™ Antimicrobial Powder Coating



  • Eliminates 99.9% of surface bacteria within 24 hours of exposure Models

Specifications

Overview

  • Nominal Height:
    50" (127.0 cm)
  • Nominal Width:
    64.8" (164.59 cm)
  • Nominal Length:
    31" (78.74 cm)
  • Internal Height:
    28.5" (72.39 cm)
  • Internal Width:
    59.4" (150.88 cm)
  • Internal Length:
    24.4" (61.98 cm)

General Specifications

  • Nominal Size:
    1.5 meter (5')
  • Internal Work Area, Space:
    0.9 m² (9.6 ft²)
  • Average Airflow Velocity:
    0.45 m/s (90 fpm) at initial setpoint
  • Air Volume:
    1771 m3/hr (1042 cfm)
  • ULPA Filter Typical Efficiency:
    > 99.999% at particle size between 0.1 to 0.3 μm
  • Sound Emission Per IEST-RP-CC002.2:
    58.0 dBA
  • LED Lamp Intensity at Zero Ambient:
    1204 Lux (112 foot candles)
  • Net Weight:
    180 Kg (397 lbs)
  • Shipping Weight:
    237 Kg (522 lbs)
  • Shipping Dimensions, Maximum (W x D x H):
    1720 x 900 x 1590 mm (68" x 35" x 62")
  • Shipping Volume, Maximum:
    2.5 m³ (87 ft³)

Cabinet Construction

  • Main Body:
    1.2 mm (0.05") 18-gauge electro-galvanized steel with white oven-baked epoxy-polyster powder-coated finish.
  • Work Zone:
    1.2 mm (0.05") 18-gauge stainless steel, grade 304, with 4B finish.
  • LHS Side Walls - Interior:
    1.2 mm (0.05") 18-gauge stainless steel, grade 304, with 4B finish.
  • LHS Side Walls - Exterior:
    1.2 mm (0.05") 18 gauge electro-galvanized steel with white oven-baked epoxy-polyester powder-coated finish.

Electrical Power Rating 9 (110-130 VAC, 50/60 Hz, 1 phase)

  • Cabinet Full Load Amps (FLA):
    12.4 A
  • Optional Outlets (FLA):
    6 A
  • Cabinet Nominal Power (W):
    273
  • Heat Rejected, BTU Per Hour:
    932
