This 30 cu. ft. touchscreen laboratory refrigerator redefines precision and user experience for critical sample storage, backed by microprocessor temperature control.

Features

The units utilize natural hydrocarbon refrigerants for EPA SNAP compliance and eco-friendly cooling. This model offers exceptional temperature uniformity and extensive data logging and charting capabilities for auditing and compliance. Access a 24-hour temperature chart and data logging capabilities through an intuitive touchscreen interface. Experience an extensive array of customizable audible and visual alarms, including high/low-temperature, sensor error, power failure, door ajar, and low battery alerts, all supported by a battery backup and remote alarm contacts. This unit is constructed with durable white powder-coated steel and protected by a secure keyed door lock. Adjustable interior shelving allows for versatile organization. The CPS-HC-30R-TS refrigerator provides a reliable, energy-efficient and user-centric solution for any laboratory needing precise temperature control and data logging capabilities.

Specifications

Overview

  • Nominal Height:
    83" (210.82 cm)
  • Nominal Width:
    35.75" (90.81 cm)
  • Nominal Length:
    35.5" (90.17 cm)
  • Internal Height:
    65" (165.1 cm)
  • Internal Width:
    32" (81.28 cm)
  • Internal Length:
    22.5" (57.15 cm)
  • Capacity:
    30

General Description and Application

  • Door:
    One solid swing, right hinged, stainless steel door handle, magnetic door gasket
  • Shelves:
    Five adjustable
  • Mounting and Installation:
    Caster Platform
  • Airflow Management:
    Forced draft circulation
  • External probe access:
    3/4" probe access port on rear wall
  • Insulation:
    EPA compliant high density urethane foam
  • Exterior materials:
    Powder coated steel
  • Access control:
    Keyed door lock
  • General warranty:
    Two (2) year parts and labor warranty
  • Compressor warranty:
    Five (5) year compressor parts warranty
  • Product Weight (lbs):
    350
  • Shipping Weight (lbs):
    380
  • Rated Amperage:
    3.1 Amps
  • Power Plug/Power Cord:
    NEMA 5-15P plug, 6 ft long cord
  • Facility Electrical Requirement:
    110 - 120V AC, 15A breaker, NEMA 5-15 receptacle
  • Agency Listing and Certification:
    UL listed per UL 60335-1 and UL 60335-2-89 standards, c UL listed per CSA C22.2 No. 120 standard

Performance

  • Uniformity (Cabinet Air):
    +/- 1.6°C
  • Stability (Cabinet Air):
    +/- 1.0°C
  • Maximum Temperature Variation (Cabinet Air):
    3.6 °C Total
  • Energy Consumption (kWh/day):
    < 1.7 KWh/day
  • Average Heat Rejection (BTU/hr):
    520 BTU/hr
  • Pull Down Time to Nominal Operating Temp:
    <35 min (empty)

Refrigeration System

  • Compressor:
    Hermetic, variable speed
  • Refrigerant:
    EPA SNAP compliant R600a Isobutane
  • Condenser:
    Static - exterior walls of cabinet
  • Evaporator:
    Fin and tube design, high efficiency fan
  • Defrost:
    Off-cycle defrost, no heat added
