SmartSeal™ Pro, Automated Thermal Plate Sealer, 230V.

Features

The SmartSeal™ Pro is designed for efficient, reliable, and consistent sealing of standard microplates, deep-well plates, and PCR plates. The instrument can operate as a standalone system or be integrated into automated laboratory workflows. An Ethernet connection and API support enable communication with external automation systems, allowing the SmartSeal Pro to be incorporated into integrated and robotic laboratory workflows.


  • Broad plate compatibility: Accommodates plate heights from 3 to 63 mm, with adapters available for various plate formats.
  • Intuitive operation: Features a 7-inch color touchscreen for easy setup and operation.
  • Programmable sealing protocols: Allows users to create and save sealing protocols for efficient, reproducible workflows.
  • Built-in electronic vacuum pump: Eliminates the need for an external air source, simplifying installation and allowing greater flexibility in instrument placement.
  • Automation-ready: An Ethernet port enables integration with laboratory automation systems.
  • Automatic standby: Reduces energy consumption and helps extend the service life of the instrument.

Specifications

Overview

  • Nominal Height:
    18" (45.72 cm)
  • Nominal Width:
    8.7" (22.1 cm)
  • Nominal Length:
    14.2" (36.07 cm)

Technical Data

  • Model:
    SmartSeal Pro™
  • Supported Plates:
    ANSI/SBS standard plates, height range 3-62mm
  • Supported Roll Type:
    Easy-peel and pierce able aluminum foil, and clear qPCR heat seal
  • Supported Roll Width:
    78-84 mm
  • Temperature Range:
    25 - 200°C
  • Temperature Accuracy:
    ± 1°C
  • Temperature Increments:
    1°C
  • Pre-heating Time:
    ≤5 seconds
  • Cycle Time:
    < 20 seconds/plate
  • Sealing Time Range:
    0.5~9.9 seconds
  • Sealing Time Increments:
    0.1 sec
  • Air Source:
    Built-in
  • Display:
    7-inch color touchscreen
  • Connection Ports:
    USB, Ethernet (API available)
  • Power Input:
    AC 230 V, 50/60 Hz
  • Heating Power:
    300 W
  • Weight:
    35.2 lbs. (16kg)
