Baker - EGVF501 - 5' EdgeGARD® VF Vertical-Flow Clean Bench

Baker - EGVF501 - 5' EdgeGARD® VF Vertical-Flow Clean Bench

Baker - EGVF501 - 5' EdgeGARD® VF Vertical-Flow Clean Bench

Contact Brent for Assistance

Need help right away? Give our customer service team a call for immediate attention

(510) 909-5846
Brent Kolhede

Ask About This Item

Add the product to a quote to receive more information.

Ask an Expert
The EdgeGARD® VF is a vertical-flow recirculating air clean bench that provides protection for samples and work procedures where product protection and particulate control are required.

Features

Clean Benches Designed with You in Mind



  • ISO Class 4 (Class 10) cleanliness (for 0.5 micrometer particles)
  • Built for versatility, productivity, and user comfort
  • Latest extension of the EdgeGARD® clean bench line



Unlike conventional horizontal-flow clean benches, the EdgeGARD® VF provides vertical, uni-directional, and controlled airflow over the entire work surface, while reducing energy consumption, noise, and airflow turbulence.



Recognized as the industry's most reliable clean bench, this extension of Baker's EdgeGARD® brand provides lower life-cycle costs and years of trouble-free operation.

Specifications

Overview

  • Nominal Height:
    97.56" (247.8 cm)
  • Nominal Width:
    65.5" (166.37 cm)
  • Nominal Length:
    32" (81.28 cm)
  • Internal Height:
    31.81" (80.8 cm)
  • Internal Width:
    58" (147.32 cm)
  • Internal Length:
    25.13" (63.83 cm)

Technical Data

  • Nominal Size:
    5'
  • Exterior Dimensions with Stationary Stand (w x d x h [min to max]):
    65.5" x 32.0" x [89.06" - 97.56"]
  • Shipping Weight (Benchtop Model):
    499 lbs
  • Shipping Weight (with Channel Stand):
    576 lbs
  • Access Opening (Working Position):
    14"
  • Access Opening (Loading/Cleaning Position):
    30.38
  • Electrical Requirements:
    115 V, AC
  • Amps / Breaker:
    16 / 20
