The temperature display and alarm module offers an array of robust security features with a monitoring and alarm system that is 100% independent of a microprocessor temperature controller for additional product security.

The acceptable temperature ranges for vaccine storage are 36°F to 46°F (or 2°C and 8°C) in the refrigerator and -58°F to 5°F (or -50°C and -15°C) in freezers.

Environmentally friendly, natural hydrocarbon (HC) refrigerants (not containing hydrofluorocarbons) vastly reduce global-warming potential (GWP) while meeting new EPA/SNAP mandates and UL, ASHRAE compliance guidelines.

Details

• Sensor error alarm
• Power failure alarm
• Resettable 1-point Min/Max History
• Remote alarm contacts
• Alarm validation (audible, visual, and remote alarm)
• Alarm mute with ring back
• 5 total shelves, 3 adjustable plus 2 additional
• Vaccine storage power cord warning label
• Forced draft air circulation
• Keyed door lock
• Magnetic door gasket for positive seal
• Heavy duty door handle
• Swivel casters (3.5")
• LED interior lights are safety shielded and switch controlled
• Hydrocarbon, natural refrigerant (R290)
• Pharmacy refrigerator/freezer toolkit and temperature logs
• Two year parts and labor warranty, plus an additional three year compressor parts warranty

Temp Controller

• Microprocessor Temperature Controller
• Adjustable operating temperature range: 36°F to 46°F (2°C to 8°C)
• Temperature monitor device (TMD) complies with the current CDC guidelines, with 3 years certification of calibration, "buffered" probe in the product simulated solution, min/max memory. F/C switchable, field installable, and visual & audible temp alarm
• Standard Digital Temperature Display and Alarm Module with battery back-up to support temperature monitoring and alarms
• Sample simulated digital temperature display; 1° Resolution
• Adjustable temperature display in Celsius or Fahrenheit
• Audible and visual high/low temperature alarms
• 2 probes; 1 in air and 1 in sample bottle
