American Biotech Supply - ABT-HC-MFP-20 - 20 Cu. Ft. Capacity Standard Manual Defrost Laboratory Freezer with Natural Refrigerants

American Biotech Supply - ABT-HC-MFP-20 - 20 Cu. Ft. Capacity Standard Manual Defrost Laboratory Freezer with Natural Refrigerants
American Biotech Supply - ABT-HC-MFP-20 - 20 Cu. Ft. Capacity Standard Manual Defrost Laboratory Freezer with Natural Refrigerants

American Biotech Supply - ABT-HC-MFP-20 - 20 Cu. Ft. Capacity Standard Manual Defrost Laboratory Freezer with Natural Refrigerants

Contact Brent for Assistance

Need help right away? Give our customer service team a call for immediate attention

(510) 909-5846
Brent Kolhede

Ask About This Item

Add the product to a quote to receive more information.

Ask an Expert

The Standard Hydrocarbon Manual Defrost Freezers take a large step forward in performance from past solid door general purpose units; offering a microprocessor temperature controller allowing for the precise temperature management necessary for critical samples and supplies.



Features

Models are ETL Listed and are backed by a two year parts and labor warranty, plus additional three year compressor parts warranty.



Models utilize environmentally friendly, natural hydrocarbon (HC) refrigerants (not containing hydrofluorocarbons) vastly reduce global-warming potential (GWP) while meeting new EPA/SNAP mandates and UL, ASHRAE compliance guidelines.



Details



  • One solid swing door, right hinged, not reversible
  • Six fixed shelves
  • Keyed door lock
  • Magnetic door gasket for positive seal
  • Leveling legs
  • Probe access port (3/4")
  • Powder coat exterior
  • High density urethane foam cabinet and door insulation
  • Natural, Hydrocarbon Refrigerant (R290)
  • Two year parts and labor warranty



Temp Controller



  • Microprocessor temperature controller
  • Digital temperature display
  • Audible and visual high and low temperature alarms
  • Remote alarm contacts
  • 2 probes; 1 in air and 1 in glycol bottle
  • Adjustable operating temperature range:-15°C – -25°C

Specifications

Overview

  • Nominal Height:
    74.63" (189.56 cm)
  • Nominal Width:
    30.75" (78.11 cm)
  • Nominal Length:
    29" (73.66 cm)
  • Internal Width:
    25.88" (65.74 cm)
  • Internal Length:
    21.75" (55.25 cm)
  • Capacity:
    20

General Description and Application

  • Door:
    1 solid swing door, right hinged
  • Shelves:
    6 Fixed
  • Freezer Compartments:
    1
  • Baskets:
    Non-applicable
  • Mounting:
    Leveling Legs
  • Interior Lighting:
    Non-applicable
  • Airflow Management:
    Non-applicable
  • External Probe Access:
    Rear wall port (3/4") dia.
  • Exterior Materials:
    White powder coated steel
  • Access Control:
    Keyed door lock
  • Shipping Weight:
    240 Ibs
  • Rated Amperage:
    5.5 Amps
  • Power Plug/Power Cord:
    NEMA 5-15 Plug, conforms to UL471 requirements
  • Facility Electrical Requirement:
    115V, 60 Hz
  • Agency Listing And Certification:
    ETL, C-ETL listed , Energy Star Certified

Refrigeration System

  • Refrigerant:
    R290
  • Defrost:
    Manual

Controller, Configuration, Alarms and Monitoring

  • Controller Technology:
    Microprocessor temperature controller with digital temperature display, °C/°F switchable
  • Display Technology:
    Standard Digital Temperature Display
  • Adjustable Temperature Range:
    -15°C to -25°C
  • External Alarm Connection:
    State switching remote alarm contacts
  • Alarms:
    Audible and visual high and low temperature alarms
  • Controller Probe:
    2 Probes; 1 in air and 1 in sample bottle
  • Disclaimers:
    Defrosting of the unit will need to be performed periodically to prevent severe ice build-up; Indoor use only, +18°C to +26°C (+65°F to +78°F), <70% RH
